Analyze die geometry with precision, detect die wear in just a few minutes and achieve consistent cable diameter using reliable die inspection technology.
| Parameter | If Too Small | Effects | If Too Large | Effects |
|---|---|---|---|---|
| Entry Angle | Sharp entry | Scratches, surface cracks, lubrication problems |
Overwide entry | Poor guidance into reduction zone, lubricant washout |
| Reduction Angle | Too shallow | High friction, overheating, high force, more die wear |
Too steep | Poor material flow, internal cracks, uneven reduction |
| Bearing Length | Too short | Size instability, ovality, poor surface |
Too long | Excess friction, higher drawing force, die overheating |
| Exit Angle | Too small | Wire rubs against die exit, surface scratches |
Too large | Weakens die edge, risk of premature die chipping |
High-precision optical coordinate measuring machines with granite guideways, air balanced z-axis and servo controlled motion provide fast, reliable and accurate inspection for manufacturing industries such as aerospace, automotive, heavy engineering and defence
How the Right Tools can help you to Avoid them
Explore our various kinds of advanced measurement solutions
Discover SIPCONβs smart Die Inspection Microscope in Australia
Some important factors you must know before buying drawing die inspector in Australia
Get A Quote
Custom Quotes, Detailed Specs, or Pricing.
